Arrow HOW To : Make Custom Go-pro Camera ARM Mount (lots of picture)

this how to is really easy and cheap, its been done before, cause i saw my buddy having this setup at the track.. super cheap and easy, im am showing you the basic, form here you can think of all the other mounts style you can Via the suction cup and such. LETS BEGIN...


disclaimer; please take caution and use a tethering system like a shoe lace, just in case the camera fail. i am not responsible for any damage or lost to your Go-pro


-----------------------------------------------------


supplies need--

Gopro camera

gopro misc mounts

1/8" X 1/2" - 3' aluminium sticks.( you can find this at Lowesl, cost $4 a stick)

power Drill

Drill bit size 13/64

Hacksaw

some tape

a block of wood for back board(not necessary)

some patience.



-------------------------


i'm sure by now ya get the whole idea already,

well pretty simple.. ima let the picture explain themselves a bit.

Get your 2 sticks, cut them to desire lenth..1 foot...etc. i have not cut mines yet. hack it.

tape them both up so they are nice an flush, so when you drill it, you wont be off.

get your 13/64 bit set in your drill and drill the center.


DRILL IT SLOWY!! I MEAN I, DONT APPLY SO MUCH PRESUURE. LET THE DRILL DO THE WORK OR ELSE YOUR GOING TO GET AN CRAPY HO.





clean it and mount that suck on..

if you have a grinder, you can also grind the ends so they're more of a "U" shape rather than a edge. therefore it can adjust when mounted..

tada..

hope this gives ya some ideas..

yes i know youll look a bit weird now with a camera sticking out a foot of your helmet.










__________________



My Ride Report :

-Alaska,The Last Frontier

-
Quote:
Originally Posted by crash a-ron View Post

"To travel by motorcycle there are 3 things- youth, time, and money. You only get 2. Pick wisely."
Nuttynu is offline   Reply With Quote
The Following User Says Thank You to Nuttynu For This Useful Post:
SilentSun (11-17-2012)
Sponsored Links
Advertisement

Old 11-17-2012, 11:32 PM   #2
Nuttynu
BOTM Winner 1/13

Nuttynu's Avatar

Join Date: Feb 2011
Location: ANCHORAGE, AK
Posts: 5,794
Images: 1
Thanks: 1,831
Thanked 374 Times in 323 Posts
Feedback Score: 4 reviews





enjoy. and once you make some vids , post them up...obviously i cant ride at the MOMMENT
__________________



My Ride Report :

-Alaska,The Last Frontier

-
Quote:
Originally Posted by crash a-ron View Post

"To travel by motorcycle there are 3 things- youth, time, and money. You only get 2. Pick wisely."
Nuttynu is offline   Reply With Quote
Old 11-17-2012, 11:56 PM   #3
SilentSun
AMA Supersport Racer

SilentSun's Avatar

Join Date: Nov 2011
Location: Australia
Posts: 1,116
Thanks: 164
Thanked 159 Times in 144 Posts
Feedback Score: 1 reviews
Awesome post, might give this a shot after christmas - hint hint santa..

__________________
----------------
600rr 11
SilentSun is offline   Reply With Quote
Old 12-10-2012, 12:47 PM   #4
harry-nyc
AMA Supersport Racer

harry-nyc's Avatar

Join Date: Sep 2008
Posts: 868
Thanks: 86
Thanked 79 Times in 68 Posts
Feedback Score: 4 reviews
Why would you want to do this? Wouldn't this get in the way as soon as you tuck behind the windscreen? Why not just mount the camera on your bike or on top of the helmet?

I would also see this as a hazard if you go down. I can't see some trackday organizations allowing this to pass tech. Now if you installed it at the tail of the bike to get a better angle for your body position by having the camera back further then I'd understand.

I still give you a +1 for creativeness.
harry-nyc is offline   Reply With Quote
Old 12-10-2012, 01:23 PM   #5
PhillyB
AMA Supersport Racer

PhillyB's Avatar

Join Date: Nov 2011
Posts: 552
Thanks: 5
Thanked 35 Times in 32 Posts
Feedback Score: 1 reviews
Agreed with Harry. Very creative way to mount but there's no way most of the track orgs I ride with would ever let my helmet pass spec, and frankly I'm not sure if I'd even want that last one on my helmet lol. Very cool though


Sent from my Motorcycle iPhone app
PhillyB is offline   Reply With Quote
Old 12-10-2012, 02:28 PM   #6
Nuttynu
BOTM Winner 1/13

Nuttynu's Avatar

Join Date: Feb 2011
Location: ANCHORAGE, AK
Posts: 5,794
Images: 1
Thanks: 1,831
Thanked 374 Times in 323 Posts
Feedback Score: 4 reviews
Thanks guys. But most likely I won't be connecting this to my helmet. It'll be more on the bike . I just hady helmet for example .
