post #5 of (permalink) Old 07-16-2013, 05:29 PM Thread Starter
gioarge
AMA Supersport Racer

gioarge's Avatar

Join Date: Apr 2012
Location: Italy
Posts: 1,409
Thanks: 269
Thanked 263 Times in 247 Posts
Here the list Honda Part Numbers vs LighTech codes. I made also a PDF with also the Honda diagram for each part, if you are interested just ask.

FRONT FENDER
Honda PN: 90118-MEL-000 / Qty = 6
LighTech: 002 – M6 – 20

MIDDLE COWL / LOWER COWL (LEFT)
Honda PN: 90106-KY2-701 / Qty = 3
LighTech: 1003

Honda PN: 90113-MCJ-000 / Qty = 2
LighTech: 002 – M5 – 15

Honda PN: 90120-MFJ-A40 / Qty = 1
LighTech: 002 – M5 – 25

MIDDLE COWL / LOWER COWL (RIGHT)
Honda PN: 90106-KY2-701 / Qty = 1
LighTech: 1003

Honda PN: 90118-MR1-000 / Qty = 1
LighTech: 002 – M6 – 15

Honda PN: 90113-MCJ-000 / Qty = 2
LighTech: 002 – M5 – 15

Honda PN: 90120-MFJ-A40 / Qty = 1
LighTech: 002 – M5 – 25

Upper COWL
Honda PN: 90113-MCJ-000 / Qty = 4
LighTech: 002 – M5 – 15

Honda PN: 90119-MFL-D20 / Qty = 2
LighTech: 003 – M5 – 15

Honda PN: 90119-MJC-A00 / Qty = 2
LighTech: 003 – M5 – 20

TOP SHELTER
Honda PN: 90106-MBY-000 / Qty = 2
LighTech: 1023

Honda PN: 90114-MFJ-D00 / Qty = 2
LighTech: 003 – M5 – 10
Note: Adjustments needed, see below.

MUFFLER
Honda PN: 90115-MFJ-D00 / Qty =
LighTech: 003 – M5 – 10
Note: Here Honda provides a special screw, but a normal one is fitting perfectly.

SWINGARM
Honda PN: 90113-MAS-E00 / Qty = 3
LighTech: 984

Manual adjustments are needed just on a set of screws, so here the procedure I made (with a Dremel could be more easy):

Out of the shelves

Cutting operation

Little adjustments

Use a nut to thread the screw

The end

Last edited by gioarge; 07-17-2013 at 02:04 PM.
